Paradox M25

System Overview

Hybrid System

Security, Video, Control and Access

The Paradox M25, a variant of the Paradox M Head units, is a versatile and powerful wireless/wired hybrid compact head unit. The wireless section uses Gaussian Frequency Shift Keying (GFSK) technology, offered in both 868 MHz and 914 MHz bands. It employs advanced frequency and encryption hopping to protect against unauthorized access, ensuring data security and an ultra-fast connection.

Powerful yet ultra-small and compact, the M25 is ideal for medium-sized homes, businesses, and large apartments. Its sleek design allows it to be installed anywhere, secured and hidden.

The M25 provides enhanced, trusted security with true direct-connect, ensuring it remains constantly online with supervised direct reporting, independent of the cloud or third-party points of failure. Its direct reporting supports up to four simultaneous supervised connections to IPC10 IP receivers. Unlike cloud-dependent systems, the M system’s powerful communication enables direct monitoring without relying on the cloud, reducing potential points of failure.

The M25 includes powerful programmable output control, enabling activation through manual settings, scheduled events, temperature triggers, or system events. The system is expandable with M wireless, Ethernet, or hard-wired security devices. It also supports integration with video monitoring and verification, access control, and home automation (to be released in 2025).

The M25 utilizes fourth-generation cloud services with the Paradox identifier ecosystem for fast, reliable, and secure system access, together with the BlueEye mobile application, IPC10 receiver, and the Service Dealers/Companies Portal. The ecosystem verifies user identity with two-way authentication for increased security. The system offers ultra-fast and easy installation using a single RJ45 cable for both PoE and Ethernet, eliminating the need for a separate power supply or additional wiring, thereby saving valuable time and effort. Built-in Wi-Fi can be used

as the primary or backup channel, while LTE provides an additional communication channel for enhanced redundancy and reliability.

Wireless nodes or Ethernet extensions can be added using Paradox’s powerful and intuitive auto-learn feature. For pre-installation preparation, installers can scan QR codes or manually enter the serial number, ensuring a fast and efficient installation process that saves valuable time.

Programming is powerful and simple, with a user- friendly interface and application-based configuration or PC software.

All wireless modules connected to the M25 console are fully supervised and upgradable either over the air (for wireless devices) or through Ethernet (for network devices).

The M25 is CE-certified and pending compliance with European Standard (EN) certifications such as EN 50131-1, EN 50131-3, EN 50131-6, EN 50131-10, EN

50136-1, EN 50136-2, Grade 2, and Class II.
